Jeio Tech MS-33MH Multi-Position Hotplate Stirrer

SKU: AAHK34015K
BRAND:

£3,417.54

With its speed and time setting modes, Jeio Tech’s MS-33MH Multi-Position Hotplate Stirrer allows you to carry out simultaneous independent stirring at a maximum of 9 positions with stable heating at speeds from 30 to 2000rpm.

Use this quote list to submit your required products to Medline in order for a quotation.

Description

With its speed and time setting modes, Jeio Tech’s MS-33MH Multi-Position Hotplate Stirrer allows you to carry out simultaneous independent stirring at a maximum of 9 positions with stable heating at speeds from 30 to 2000rpm. This hotplate stirrer has a distinctive digital display with various settings – there are multiple speed and time setting modes, allowing various ways of multi-position stirring to meet users’ demands – single point, multiple point, whole row, whole column etc.

The intuitive, easy-to-read VFD control panel also features bright and vivid LED position indicating lamps for your convenience. Stirring is controlled by a BLDC motor and strong magnet, guaranteed to deliver high-speed and effective coupling to magnetic stirrer bars. This lab stirrer has been carefully constructed to save internal components from any spills. A non-slip silicone mat is attached to the top plate to prevent unintended slips.

Features

Performance & Convenience

  • Ideal for multiple sample testing under the same conditions
  • User-friendly operation and time setting modes single point, multiple point, whole row, whole column, etc.
  • Fast and precise stirring operations are enabled by BLDC motor and strong magnetic coupling
  • Smooth-start mechanism provides virtually no decoupling of stir bars even with viscous media
  • Instant halt of the stirring operation
  • Easy-to-read VFD and intuitive control panel

Safety

  • Unit is designed to protect internal components from accidental spills
  • Non-slip silicone plate mat is attached to the top plate to prevent unintended slips
  • Built in thermal shut off and current limit protection

Specification

Temperature Range (°C):  Ambient to +120

Display:  VFD & LED

Power (W):  600

Speed Range (rpm):  30 to 2000

Control:  Feedback control with PID

Stirring Positions:  9

Point Distance; W x D (mm):  117 x 90

Timer:  1min to 99hr 59min

Max. Load (Kg):  30

Top Plate Material:  Aluminium (plus silicone mat)

Dimensions (mm)

     Top Plate; W x D:  385 x 328

     Main Unit; W x D x H:  395 x 450 x 104

Weight (Kg):  10
