Ceti Steddy-BR Trinocular Stereo Microscope, Broad Base with 0.67x – 4.5x Plan Achromatic Objectives and 5W Transmitted plus 8W Reflected LED Illumination

SKU: 7600.0000M
BRAND:

£2,581.81

Ceti’s Steddy-BR Trinocular Stereo Microscope with Broad Base is one of Ceti’s most popular zoom microscopes. It provides high quality, wide field of view images, a wide zoom range and is highly robust and extremely well built, suitable for the most demanding uses.

Description

Ceti’s Steddy-BR Trinocular Stereo Microscope is one of Ceti’s most popular zoom microscopes. It provides high quality, wide field of view images, a wide zoom range and is highly robust and extremely well built, suitable for the most demanding uses. The Steddy-BR features a convenient 0.67x – 4.5x zoom ratio and a pair of 10x super widefield (FN 22) eyepieces, giving a total magnification range of 6.7x to 45x or, with auxiliary objectives and/or alternative eyepieces, 3.35x to 180x. These versatile stereo zoom microscopes are an excellent, professional-grade instrument choice for industry, researchers and educational establishments. ​

The optical quality is extremely good giving a bright, crisp 3D image of the specimen. The broad base is the best option for dissecting applications and applications where larger specimens are being observed. It features dual LED illumination. A photo port to allow the connection of a digital camera to capture images or videos is included as standard. The Ceti Steddy range are our most versatile stereo zoom microscopes and are an excellent, professional grade instrument choice for industry, hobbyists, researchers and educational establishments.

The Steddy stereoscopic zoom microscope is highly robust and extremely well built, suitable for the most demanding uses. The optical quality is extremely good giving a bright, crisp 3D image of the specimen.

Additional information

Pack Size

1

Features

• Broad base
• Super widefield 10x, FN 22 eyepieces for maximum field of view
• Wide magnification zoom range of 6.7x to 45x as standard (Max 3.35x to 180x with additional objectives)
• Trinocular head with photo port
• Dual LED illumination

Specification

Optical Head: Trinocular, inclined at 45° with photo port

Siedentopf: Yes (55 to 75 mm interpupillary distance)

Dioptre: Dioptric adjustment on both eyepiece tubes

Eyepieces: 10x / 22 mm super widefield

Turret Format: Single

Objectives: 0.67x – 4.5x Plan Achromatic

Objective Type: Finite

Stage Size: Rectangular support with dual coarse focus knobs and tension control

Focusing: Coaxial coarse with safety stop and tension adjustment

Illumination – transmitted: 5W LED

Illumination – reflected: 8W LED

Special Features: Broad Base, with auxiliary objectives and/or alternative eyepieces, 3.35x to 180x

Package: Dust cover, two rubber eye cups, blue filter and instruction manual

Additional Features: Cold light sources can be added

Downloads

Click here for download View File
