Sigma 2-16KHL, Refrigerated Centrifuge with Heating

SKU: 10353
BRAND:

£10,783.00

This all-rounder features user-friendly, intuitive operation. The Sigma 2-16KHL centrifuge includes integrated heating, which makes it ideal for centrifuging haematocrit tubes at 37°C body temperature. Rotors must be ordered separately.

Use this quote list to submit your required products to Medline in order for a quotation.

Description

This all-rounder features user-friendly, intuitive operation. The Sigma 2-16KHL has all the technical features of the Sigma 2-16KL plus integrated heating, which makes it ideal for centrifuging haematocrit tubes at 37°C body temperature. The Sigma 2-16KHL can also be operated with inert gas as an option.

It also boasts patented, intuitive one-button control with user-friendly illuminated buttons, as well as a convenient safety feature: cycle counting for each rotor with an indication when the rated limit is reached.

Supplied without a rotor.

Features

Spincontrol Universal controller
Backlit Start, Stop, and Lid Open buttons
Sedimentation in swing-out vials up to 4 x 100 ml or up to 20,000 x g in fixed-angle rotor
Zero-maintenance brushless drive
Rotor identification prevents overspeed operation
Stainless-steel centrifuge bowl
Imbalance switch
Easy lid opening with gas spring support
Window in lid for independent speed checking
Produced in compliance with the latest national and international standards (e.g. EN 61010-2-020)
Maximum rotor temperature +40°C to +60 °C, depending on rotor and speed
All other specifications as for Sigma 2-16KL
Calibration certificate available at an additional cost – please enquire for a quote

Specification

Max. speed (rpm): 15,300
Min. speed (rpm): 100
Max. RCF (x g): 21,913
Max. capacity (ml): 4 x 100 ml
Programs: 50
Acceleration curves: 10
Deceleration curves: 10
Cycle counting: Yes
Power consumption (W): 720
RFI suppression: EN61326
Dimensions HxWxD (mm): 310x550x570
Height with open lid (mm): 705
Weight without rotor (kg): 60
Maximum kinetic energy (Nm): 9,962
Noise level at maximum speed (approximate) with rotor 12148 (dB (A)): 65
Noise level at maximum speed (approximate), rotor 11170 (dB (A)): 63
Maximum acceleration, rotor 12148 (s): 27
Maximum acceleration, rotor 11170 (s): 22
Maximum breaking time, rotor 12148 (s): 18
Maximum breaking time, rotor 11170 (s):17
Temperature adjustment range (°C): -10 to +60
