Medline 800 Litre -86°C Ultra Low Temperature Freezer

SKU: MDULF80086

£12,892.69

The Medline LabCare+ 800 Litre -86° Ultra Low Temperature (ULT) Lab Freezer, with a dual independent refrigeration system, is one of the most advanced and secure freezers available for the storage of your invaluable samples.

After Sales Service

Service Contract

Use this quote list to submit your required products to Medline in order for a quotation.

Description

This LabCare+ 800 litre Medline ULT Laboratory Freezer reliably maintains a stable, set temperature down to -86°C and features natural, biodegradable HC cooling gases. This Ultra Low Temperature Freezer satisfies the demand for the safe, long-term storage of high-value materials and samples. This freezer incorporates two, independent refrigeration systems which, combined with an optional liquid CO2 backup system, provides a critical level of protection that is unmatched in the marketplace.

Features

The Medline LabCare+ 800 litre -86°C Ultra Low Temperature Freezer satisfies the demand for the safe, long-term storage of highly-valued materials and samples. Two independent refrigeration systems, combined with an optional liquid CO2 backup system, provides a critical level of protection that is unmatched in the marketplace.
By using two, independent refrigeration systems, all upright LabCare+ ULT freezers reliably maintain a stable, set temperature down to -86°C. Should either cooling system suffer from any unexpected failure, the other circuit (compressor) will maintain a temperature of -80°C, thus keeping all samples safe until service can be arranged.

  • 5″ Graphic LCD touchscreen controller provides easy programming and greater accuracy of temperature control
  • Temperature control range from -40°C to -86°C with datalogger and USB data download port
  • Maximum protection thanks to visual and acoustic alarm signals, used in case of; power failure, temperature deviations, probe failure, open door after 10-60 seconds, low battery or filter saturation
  • All condenser units are tested in helium chambers to check for refrigerant leaks
  • Double circuit cooling system, with independent and hermetically sealed, low-noise compressors. In case of failure of one system, the other can maintain the internal temperature at -80°C. Natural, biodegradable HC cooling gases
  • 120mm, high quality, CFC-free, VIP (Vacuum Insulation Panel) insulation. Solid door with lock and 4 inner doors to help maintain cabinet temperature during openings
  • Low power consumption and noise level



• DUAL INDEPENDENT COMPRESSOR SYSTEM – double circuit cooling system, with independent and hermetically sealed, low-noise compressors. In case of failure of one system, the other can maintain the internal temperature at -80°C

• EASY AND INTUITIVE – with large graphical touchscreen control

• PRECISE CONTROL – NTC probes with a precision of 0.1oC

• POWER FAILURE INDICATOR – with 48h battery backup (72h optionally)

• OPTIONAL RECORDS – circular recorder, Bluetooth or SD card records

• AUDIBLE AND VISIBLE ALARMS – for maximum and minimum temperatures, probe failures and open door

• REMOTE ALARM – dry contact for remote alarm

• OPTIONAL FEATURES – USB port, Bluetooth data logger, battery, RS 485 output…

• NUMERIC PASSWORD – control system protected with numeric password



Specification

Operating Temperature (°C)   -40 to ‐86
Net Capacity (L)   800
External Dimensions; W x D x H (mm)   1380 x 915 x 1986
Internal Dimensions; W x D x H (mm)   1020 x 619 x 1300
Door Opening; W x H (mm)   1046 x 1297



Cabinet Construction

     Exterior Material      Powder coated, galvanised steel

     Interior Material      AISI 304 stainless steel

Access Ports     3

Doors     1 outer, 4 inner

Outer Door Construction

     – Solid hinged door with integrated handle, heated gasket, key lock and front document holder

     ‐ Single‐handed operation

     – Easy to replace double door gasket

     ‐ Door open sensor

Shelves      3, 998 x 598mm (W x D), stainless steel

Compartments     4

Feet      Adjustable feet with lockable castors

Digital Plus Controller

     ‐ PT1000 temperature probe with precision of 0.1°C on the display

     ‐ Audible and visual warning functions in case of maximum and minimum temperature deviation, power failure, probe failure, open door

     ‐ Volt‐free contact

     ‐ USB port

     ‐ RS485 remote control interface port

     ‐ Datalogger (historical alarms and temperatures)

Backup Battery     48 hours

Defrost      Manual

Refrigerant     R600a / R1150

Power Consumption (kWh/24h)     17.50

Noise Level (dB)     52
